ERM8-012-09.0-F-DV-K-TR
Board-to-Board Connectors
ERM8-012-09.0-F-DV-K-TR
Mfr. Part No. : WERM8-2X12H09.0FDVKTR
Standalone or 100% Samtec-Compatible. Identical Specs. Plug & Play.
The compatible model of ERM8-012-09.0-F-DV-K-TR is WERM8-2X12H09.0FDVKTR. ERM8-012-09.0-L/F/S-DV-K-TR is a male connector with 2 rows and 24 pins, featuring a mated height of 14/16 mm. This board-to-board connector is resistant to both high temperature and low temperature.
Connector Series: WERM8
Number of Pins: 24
Connector Pitch: 0.80mm
Rows: 2
$3.4 $3
In Stock (1254)
Request a Quote
Basic Information

* "The parameters listed are for reference only. For detailed specifications and design drawings, please contact our online technical support team."

Category Board-to-Board Connectors
Connector Type Terminal
Connector Series WERM8
Connector Pitch 0.80mm
Rows 2
Terminal Interface Surface Mount (SMD)
Orientation Vertical
Material / Metal Phosphor Bronze
Color Red + Au-plated (10μin)
Rated Voltage (VAC/VDC) 250
Rated Current per Contact (Max.) (A) 1～2A
Plating Nickel Plating
Plating Thickness Other
Packaging Rigid Tray with Cover
Insulation Diameter (mm) 1.42
Wire Gauge (AWG) 22～30
Operating Temperature -55℃～125℃
Number of Circuits 65
